Chapter 13: Getting Started – Your First 10 Minutes

Terminal window with npm commands and robot emerging into test arena

You have read about occupancy grids, navigation loops, dual-brain controllers, and fleet coordination. Now it is time to run the thing. This chapter walks you from a fresh clone to a working navigation demo in under ten minutes. No GPU. No API key. No hardware. Just a terminal and Node.js.

Prerequisites

  • Node.js 18+ – Any LTS release from 18 onward.
  • npm – Comes with Node.js.
  • GPU with 8GB+ VRAM – Only needed for local Qwen3-VL-8B. All tests and demos run on CPU.

Optional:

  • Claude Code – Enables the /llmos slash command for agent creation.
  • OpenRouter API key – For live LLM inference without a local GPU.

Path A: Software Only (5 Commands)

1. Clone and Install

git clone https://github.com/EvolvingAgentsLabs/llmos
cd llmos
npm install

2. Run the Tests

npx jest --no-coverage

You should see 346+ passing tests across 21 suites. Every test runs without network, GPU, or hardware. If any fail on a fresh clone, check your Node.js version.

Checkpoint: Do you see green? All 346+ tests pass? If yes, the codebase is healthy.

3. Run the Navigation Demo

npx tsx scripts/run-navigation.ts --all --verbose

This runs all four test arenas with a deterministic mock LLM:

  • Simple Navigation: Corner-to-corner with 3 obstacles
  • Exploration: Reach 80% coverage of a 5m x 5m area
  • Dead-End Recovery: Escape an L-shaped corridor
  • Narrow Corridor: Thread a 0.6m gap

You will see cycle-by-cycle output: position, action chosen, distance to goal.

Checkpoint: Do all four arenas pass? You’re watching the full navigation stack – world model, candidate generator, A* planner, mock LLM – working end to end. Everything from here makes it smarter or more physical.

4. Try Real LLM Decisions

# Set your OpenRouter API key
export OPENROUTER_API_KEY=sk-or-...

# Run with Qwen3-VL-8B making every decision
npx tsx scripts/run-navigation.ts --live

# Run with simulated camera vision
npx tsx scripts/run-navigation.ts --vision

Same arenas, same code – but now a language model reasons about each cycle instead of following a script. The robot picks different routes, handles surprises differently, and explains its choices.

5. Explore the 3D UI

npm run dev

Open http://localhost:3000. The RobotWorldPanel renders the 3D arena using React Three Fiber – robot, obstacles, walls, and occupancy grid in real time.

Path B: Awaken the Physical Agent

If you have the V1 Stepper Cube Robot hardware on your desk:

# 1. Flash the motor controller (ESP32-S3)
#    firmware/esp32-s3-stepper/esp32-s3-stepper.ino
#    Set WiFi credentials first

# 2. Flash the camera (ESP32-CAM)
#    firmware/esp32-cam-mjpeg/esp32-cam-mjpeg.ino

# 3. Test the eyes
#    Open http://<ESP32-CAM-IP>/stream in browser

# 4. Test the muscles
echo '{"cmd":"move_cm","left_cm":10,"right_cm":10,"speed":500}' | \
  nc -u <ESP32-S3-IP> 4210

# 5. If you see video AND the robot moved 10cm:
#    The LLM takes over the steering wheel

Maker Checkpoint: Video at /stream? Robot moved 10cm? If both yes, skip to Chapter 15 for full calibration.

Use Claude Code for Agent Creation

If you have Claude Code installed:

/llmos Create an AI agent for a wall-avoiding robot

The SystemAgent discovers existing agents, consults memory, creates a multi-agent plan, and produces the result as markdown agent definitions in the volume system.

Key Files to Explore

Start with navigation-loop.ts. It is the center of the system. Every other file is a dependency of this one.

File What It Does
lib/runtime/navigation-loop.ts The 13-step cycle orchestrator
lib/runtime/world-model.ts 50x50 occupancy grid
lib/runtime/local-planner.ts A* pathfinding
lib/runtime/candidate-generator.ts Subgoal scoring for the LLM
lib/runtime/navigation-types.ts LLM I/O schemas
lib/hal/types.ts HAL interface (5 subsystems)
lib/runtime/dual-brain-controller.ts Instinct + planner brains
lib/runtime/test-arenas.ts 4 test environments
scripts/run-navigation.ts CLI demo script
components/robot/RobotCanvas3D.tsx Three.js 3D visualization
lib/hal/stepper-kinematics.ts 28BYJ-48 motor math
lib/hal/wifi-connection.ts UDP transport (port 4210)
firmware/esp32-s3-stepper/esp32-s3-stepper.ino Motor controller firmware
firmware/esp32-cam-mjpeg/esp32-cam-mjpeg.ino Camera streaming firmware

The Navigation Loop in 30 Seconds

graph LR
    SENSE["Sensors"] --> WM["World<br/>Model"]
    WM --> SER["Serializer"]
    SER --> CAND["Candidates"]
    CAND --> LLM["LLM"]
    LLM --> VAL["Validate"]
    VAL --> PLAN["A* Planner"]
    PLAN --> HAL["HAL"]
    HAL --> ACT["Actuators"]
    ACT --> SENSE

    style LLM fill:#b45309,color:#fff
    style PLAN fill:#1e3a5f,color:#fff

The NavigationLoop class orchestrates this cycle. It does not run the LLM itself. It assembles the input, delegates to whatever InferenceFunction you provide, and processes the output. This is the key design decision that makes the system both testable (mock the LLM) and backend-agnostic (swap OpenRouter for local inference).

What to Try Next

  1. Design your own arena – Edit lib/runtime/test-arenas.ts. Add walls, obstacles, a start pose and goal. Run with --arena your_key.

  2. Dive into the brain – Chapter 3: The World Model explains how 50x50 cells represent an entire room.

  3. Run with a real LLM – Set OPENROUTER_API_KEY and use --live to watch Qwen3-VL-8B make navigation decisions.

  4. Understand the HAL – Chapter 7 shows how the same code drives both simulation and real hardware.

  5. Build the robot – Chapter 15 walks through assembly, calibration, and first autonomous navigation.

Chapter Summary

From clone to running demo in five commands: install, test, run, explore, build. The mock LLM makes everything work without API keys or hardware. The four test arenas exercise different navigation challenges. The --live flag brings real LLM reasoning. And the /llmos command connects you to the development-time intelligence for agent creation.

Everything else in this book is about understanding what happens inside those five commands.
