Chapter 12: 346+ Tests – Proving the System Works

Wall of green checkmark badges with robot as quality inspector

A navigation system that cannot be tested is a navigation system that cannot be trusted. When your robot is threading a 0.6-meter corridor at walking speed, you do not want to discover a coordinate system bug for the first time on live hardware. The LLMos test suite exists to make sure that every component – from individual grid cells to full end-to-end navigation runs – behaves exactly as specified, every single time. At the time of writing, the suite contains 346 tests across 21 test suites. Every one of them runs without a network connection, without a GPU, and without a real LLM.

Test Philosophy

The core design principle is simple: every module has its own test file. The test file lives in __tests__/lib/runtime/ mirroring the source layout under lib/runtime/. If you touch world-model-bridge.ts, you run world-model-bridge.test.ts. No exceptions.

The second principle is equally important: tests run in isolation from the real world. No network calls. No GPU inference. No HTML canvas rendering. The system is designed from the ground up to be testable. The InferenceFunction abstraction in the NavigationLoop means you can swap a real Qwen3-VL-8B backend for a three-line mock function and the loop does not know the difference.

// lib/runtime/navigation-loop.ts

export type InferenceFunction = (
  systemPrompt: string,
  userMessage: string,
  images?: string[]
) => Promise<string>;

This type signature is the seam that makes the entire navigation stack testable. The loop assembles a prompt, calls whatever function you hand it, and parses the result. In production, that function hits OpenRouter or a local Qwen3-VL-8B server. In tests, it returns a hardcoded JSON string.

The Test Stack

The suite uses Jest with ts-jest for TypeScript compilation and jsdom as the test environment. The configuration is minimal:

// jest.config.js

const nextJest = require('next/jest')

const createJestConfig = nextJest({
  dir: './',
})

const customJestConfig = {
  setupFilesAfterSetup: ['<rootDir>/jest.setup.js'],
  testEnvironment: 'jest-environment-jsdom',
  preset: 'ts-jest',
}

module.exports = createJestConfig(customJestConfig)

Build and test commands:

  • Build: npm run build (Next.js 14.1.0)
  • Type check: npx tsc --noEmit
  • Tests: npx jest --no-coverage

Key Testing Patterns

Pattern 1: WorldModel Singleton Cleanup

The WorldModel uses a singleton pattern keyed by device ID. If one test creates a world model for device "test-1" and the next test creates another for "test-1", they share state. This is a leak. Every test file that touches the WorldModel must clean up after itself:

// __tests__/lib/runtime/world-model-bridge.test.ts

import { clearAllWorldModels } from '../../../lib/runtime/world-model';

afterEach(() => {
  clearAllWorldModels();
});

The clearAllWorldModels() function wipes the singleton map. Forget this call and you will spend an hour debugging a test that passes alone but fails in the full suite.

Pattern 2: Disabling Canvas in Tests

The MapRenderer generates PNG map images using an HTML canvas. jsdom does not provide a real canvas implementation. Any test that runs the NavigationLoop must disable map generation:

const loop = new NavigationLoop(bridge, mockInfer, {
  generateMapImages: false,
});

Without this flag, the renderer will throw when it tries to call canvas.getContext('2d').

Pattern 3: The Coordinate System Pitfall

The WorldModel grid is centered at offset (25, 25). When you call updatePose(0, 0, 0), the robot is at world origin, which maps to grid cell (25, 25). That cell gets marked as explored. If your test checks that the grid center is unknown after setup, it will fail because the robot’s initial pose already modified it. Use offset positions when testing grid updates:

// Good: robot at offset, center cell stays unknown
bridge.updateRobotPose({ x: 1.0, y: 1.0, rotation: 0 });

// Gotcha: robot at origin, marks grid center as explored
bridge.updateRobotPose({ x: 0, y: 0, rotation: 0 });

Pattern 4: Mock Inference

The end-to-end tests create a deterministic mock LLM that parses candidates from the prompt text and always picks the highest-scoring one:

// __tests__/lib/runtime/navigation-e2e.test.ts

function createMockLLM(): InferenceFunction {
  return async (
    _systemPrompt: string,
    userMessage: string,
    _images?: string[]
  ): Promise<string> => {
    // Parse candidates from the prompt text
    const candidateRegex = /(\w+)\s+\[(\w+)\]\s+\(([^)]+)\)\s+score=([0-9.]+)/g;
    const candidates: Array<{
      id: string; type: string; pos: string; score: number
    }> = [];

    let match;
    while ((match = candidateRegex.exec(userMessage)) !== null) {
      candidates.push({
        id: match[1],
        type: match[2],
        pos: match[3],
        score: parseFloat(match[4]),
      });
    }

    // Pick best candidate...
  };
}

This approach tests the full pipeline – serialization, prompt assembly, response parsing, path planning – without requiring any LLM inference. The mock is deterministic, so test results are reproducible across machines.

For simpler unit tests, an even lighter mock suffices:

const mockInfer = async () => JSON.stringify({
  action: { type: 'MOVE_TO', target_id: 'c1' },
  fallback: { if_failed: 'EXPLORE' },
  explanation: 'test'
});
const loop = new NavigationLoop(bridge, mockInfer);

Test Arenas

The file lib/runtime/test-arenas.ts defines four predefined environments for end-to-end testing. Each arena specifies walls, obstacles, beacons, a start pose, a goal, and success criteria.

// lib/runtime/test-arenas.ts

export interface TestArenaConfig {
  name: string;
  description: string;
  world: Robot4World;
  startPose: { x: number; y: number; rotation: number };
  goal: { x: number; y: number; text: string } | null;
  criteria: SuccessCriteria;
}

export interface SuccessCriteria {
  goalToleranceM: number;
  maxCollisions: number;
  minExploration: number;
  maxCycles: number;
  maxStuckCounter: number;
}

The four arenas cover distinct navigation challenges:

Arena Challenge Key Constraint
Simple Navigation Corner-to-corner with 3 obstacles 0 collisions, 100 cycles max
Exploration Reach 80% coverage of 5x5m area No goal, 150 cycles max
Dead-End Recovery Escape L-shaped corridor 0 collisions, 120 cycles max
Narrow Corridor Thread a 0.6m gap 0 collisions, 80 cycles max

The ARENA_SIMPLE_NAVIGATION puts the robot in the bottom-left corner facing northeast with three circular obstacles between it and the top-right goal. Zero collisions allowed, 100 cycle limit. The arena definition in lib/runtime/test-arenas.ts specifies walls as line segments, obstacles as circles with position and radius, and criteria as hard pass/fail thresholds.

The Test Suite at a Glance

The 21 test suites in __tests__/lib/runtime/ cover the full stack: world model (bridge, serializer, metrics, provider), navigation (types, e2e, runtime, LLM corrections), vision (simulator, scene bridge, pipeline e2e), sensors (sensor bridge), planning (candidate generator, local planner), the Phase 5 additions (predictive world model, fleet coordinator, HAL bridge, UI bridge, OpenRouter inference), and the V1 hardware layer (stepper kinematics, WiFi connection, firmware safety configuration, serial protocol, command validator).

Chapter Summary

The test suite is not an afterthought. It is the foundation that makes rapid development possible. The InferenceFunction abstraction decouples the navigation loop from any real LLM. The singleton cleanup pattern prevents cross-test contamination. The four test arenas provide structured challenges that exercise different navigation capabilities. When all 346 tests pass, you know that the occupancy grid, the serializer, the candidate generator, the local planner, the prompt builder, the decision parser, and the end-to-end pipeline all agree on how the robot should behave.
